E&H 743-MT Metalized PVF Insulation Blanket Cover Splicing Tape | BMS 5-157 Rev. K | GAT100FR1 | FAR 25.856(A) | Tedlar

Please Note: All E&H products have a 1-2 weeks lead time

The aerospace industry's standard metalized insulation blanket cover splicing tape — meeting Boeing BMS 5-157 and Gulfstream GAT100FR1 specifications for the fabrication and installation of aircraft thermal and acoustic insulation blankets. The distinctive dull gray metalized PVF (Tedlar) film provides reliable identification on the aircraft, while the highly fire-retardant acrylic adhesive delivers 0-second flame time and outstanding performance across extreme temperature ranges. E&H 743-MT is a dull gray metalized polyvinyl fluoride (PVF/Tedlar) film tape with a 10x10 visual scrim reinforcement and a highly fire-retardant acrylic pressure-sensitive adhesive. Manufactured by E&H Laminating & Slitting Company — the recognized specialist in aircraft insulation blanket tapes — it passes the FAA Critical Radiant Heat Panel test, FAR Part 25.853 (A or B), FAR Part 25.856(A), BSS-7230 12-second vertical burn, and meets Boeing BMS 5-157 Rev. K Type I Class I Grade A Form I Comp MPVF and Gulfstream GAT100FR1. Minimum 18-month shelf life in cool, dry storage.

Key Features

• Dull gray metalized PVF (Tedlar) film backing — Distinctive appearance for easy identification; durable and chemically resistant film used in aircraft insulation blanket covers worldwide
• 10x10 visual scrim reinforcement — Provides dimensional stability and controlled tear for precise fabrication and field installation
• Highly fire-retardant acrylic adhesive — 0-second flame time and no drips in 12-second vertical burn testing; burn length 1.9 inches maximum
• FAA Critical Radiant Heat Panel pass — Meets the most demanding FAA heat release requirement for aircraft interior materials
• Boeing BMS 5-157 Rev. K approved — Type I, Class I, Grade A, Form I, Comp MPVF — the primary Boeing specification for metalized PVF insulation blanket tape
• Gulfstream GAT100FR1 approved — Meets Gulfstream's fire-retardant insulation blanket tape specification
• Wide temperature performance — Maintains adhesion from −65°F to 160°F tested; peel strength increases with temperature exposure
• 18-month minimum shelf life — Suitable for MRO stockpile and blanket shop storage

Applications

• Fabrication of aircraft insulation blanket covers (Boeing BMS 5-157 approved)
• Installation and securing of thermal and acoustic insulation blankets
• Sealing sewn seams on insulation blanket covers
• Closing fabrication slits and holes around brackets, conduits, and other objects after installation
• Insulation blanket repair and MRO maintenance on commercial, business, and military aircraft

Specifications

• Backing — Dull gray metalized polyvinyl fluoride (PVF/Tedlar) film, 10x10 visual scrim
• Adhesive — Highly fire-retardant acrylic pressure-sensitive
• Tensile strength — 10.3 lb/in average (45.83 N/25mm)
• Peel strength (room temp) — 3.2 lb/in width (14.24 N/25mm)
• Peel strength (120°F/100% RH) — 3.8 lb/in width (16.91 N/25mm)
• Peel strength (160°F) — 3.6 lb/in width (16.02 N/25mm)
• Peel strength (−65°F) — 3.0 lb/in width (13.35 N/25mm)
• Weight — 3.0 oz/sq yd ±0.3 oz (101.7 g/m² maximum)
• Color — Dull gray (metalized)
• Shelf life — Minimum 18 months in cool, dry storage

Flammability Performance

• Burn length — 1.9 inches maximum (12-second vertical burn)
• Flame time — 0 seconds
• Drip extinguishing time — No drips

Certifications & Approvals

• Boeing — BMS 5-157 Rev. K, Type I, Class I, Grade A, Form I, Comp MPVF
• Gulfstream — GAT100FR1
• FAA — Critical Radiant Heat Panel FAR 25.856(A)
• FAA — FAR Part 25.853 (A or B)
• Boeing — BSS-7230 12-second vertical burn

Product Attributes

• Manufacturer P/N — E&H 743-MT
• Color — Dull gray (metalized)
• Country of Origin — United States
• Manufacturer — E&H Laminating & Slitting Company, Paterson, NJ
