Nitto P-629 White 6.8 Mil Cargo Pit Seam Tape
Nitto P-629 White 6.8 Mil Cargo Pit Seam Tape
Couldn't load pickup availability
Nitto P-629 is a modified-acrylic, flame-retardant, single-sided glass cloth tape engineered for the aerospace industry. Its bright white glass cloth backing blends seamlessly with Tedlar® (PVF) cargo liner panels, while the conformable cloth construction wraps contoured surfaces and mechanical fasteners with ease. The trusted choice for sealing cargo pit panel seams, it bonds firmly to new and worn Tedlar liners and provides a durable flame-retardant barrier in aircraft cargo compartments.
Designed for cargo bay seam and corner sealing, its specially formulated modified-acrylic adhesive delivers reliable, lasting bonds to PVF cargo liner panels and outstanding abrasion resistance for long service life. A bright blue HDPE liner increases ease of application and clean handling, and the tape is formulated without Penta, Octa, or Deca brominated diphenyl ether (per EU directive 2003/11/EC) and contains no heavy metals such as antimony trioxide — an environmentally responsible, RoHS-compliant choice for MRO and AOG line maintenance.
Manufacturer's Certificate of Conformance included FREE of charge.
Key Features
- Bright white glass cloth backing — Blends well with Tedlar® (PVF) cargo liner panels; abrasion resistant and durable
- Flame-retardant barrier — Provides a flame-retardant seal over PVF cargo pit panel seams
- Modified-acrylic adhesive — Bonds very well to new and worn Tedlar cargo liner panels
- Conformable — Glass cloth backing applies smoothly over contoured surfaces and mechanical fasteners
- Bright blue HDPE liner — Increases ease of application and clean handling
- Environmentally responsible — Formulated without Penta/Octa/Deca BDE (EU 2003/11/EC) and no heavy metals such as antimony trioxide; RoHS compliant
- Multi-spec approved — Meets FAA, Boeing, and Airbus cargo compartment standards
Applications
- Flame-retardant barrier over Tedlar® (PVF) cargo pit panel seams
- Sealing seams and corners of aircraft cargo liner panels
- Conformable application over contoured surfaces and mechanical fasteners
- Cargo bay liner repair during MRO and AOG line maintenance
- Covering pins, rivets, and fasteners in cargo compartments
Specifications
| Backing | Bright white glass cloth |
| Adhesive | Modified acrylic (pressure sensitive), flame retardant |
| Liner | Bright blue HDPE |
| Total tape thickness | 6.8 mil (0.17 mm) |
| Weight | 6.9 oz/yd² (0.23 kg/m²) |
| Tensile strength | 150 lb/in (530 N/20mm) |
| Elongation | 5% |
| Adhesion to steel | 45 oz/in (9.9 N/20mm) — 180° peel |
| Operating temperature | −13°F to +248°F (−25°C to +120°C) |
| Color | White (bright blue liner) |
| Shelf life | 24 months from date of shipment; store at 50–80°F (10–27°C), 25–50% R.H., out of direct sunlight |
| Liner options | P-629 (standard liner), P-629SL (skip-slit liner), P-629PRL (printed liner) |
Product Attributes
| Manufacturer | Nitto, Inc. |
| Manufacturer P/N | P-629 |
| Document Code | PDS-P-629-10-24 |
| Color Family | White |
| Pack Quantity | 1 Roll or Case |
| RoHS | Compliant |
Certifications & Approvals
- FAA — FAR 25.853(a), 25.855(d), and 25.856(a) for aircraft cargo compartment use
- Boeing — BMS 5-146 Type I, Class 1, Grade A
- Airbus — ABD0031, Paragraphs 7.3.2 & 7.4 (P-629); ABS 5649
- Boeing Service Letters — 737-SL-25-115-B, 747-SL-25-195-B, 757-SL-25-085-B, 767-SL-25-112-B, 777-SL-25-037-B
- UL-510 & CSA C-22-2 — Listed
- Manufactured under Nitto's ISO / IATF / AS quality system; RoHS compliant
- Current lots ship with a Nitto Certificate of Conformance
