Protex 10V Vinyl-Coated Latex Protective Paper | Boeing BAC 5034
Protex 10V by Mask-Off is a 10 mil latex-saturated protective paper with a vinyl coating on one side for enhanced abrasion resistance — the aerospace-grade surface protection paper (often called elephant skin) engineered to protect acrylic and polycarbonate windows, canopies, windshields, bare metal, and painted surfaces where added abrasion resistance is required. Qualified to Boeing BAC 5034 and trusted across aerospace MRO and manufacturing for protecting high-value surfaces during paint, fabrication, and assembly operations.
Its natural latex adhesive provides reliable hold during operations without damaging sensitive surfaces, and the flat release liner allows this latex-saturated paper to be die-cut into custom shapes and sizes. The silicone-free adhesive avoids contamination risk on critical aerospace surfaces.
Manufacturer's Certification included FREE of charge.
Key Features of Protex 10V Protective Paper
- Vinyl-coated latex-saturated paper — Enhanced abrasion resistance on the coated side for demanding surface protection
- Natural latex adhesive — Reliable hold without damaging acrylic, polycarbonate, painted, or bare metal surfaces
- Silicone-free adhesive — No silicone contamination risk on critical aerospace surfaces
- Die-cuttable — Flat release liner allows conversion into custom shapes and sizes
- Boeing BAC 5034 qualified — Type IV, Class 1, Grade A
- AS9100C & ISO 9001:2008 manufacturer — Produced by a quality-certified aerospace supplier
What Is Protex 10V Used For?
- Protection of acrylic and polycarbonate windows, canopies, and windshields
- Bare metal and painted surface protection where abrasion resistance is required
- Paint masking on aircraft structures
- Leading edge and wing walk protection
- Surface protection for plastics, plexiglass, and glass
Protex 10V Specifications
| Substrate | Latex-saturated paper with vinyl coating (one side) |
| Adhesive | Natural latex (silicone-free, PSTC-1 Modified) |
| Liner | Flat (release liner — die-cuttable) |
| Thickness | 9–12 mil (nominal 10 mil) |
| Basis weight | 80–100 lbs / 3,000 sq. ft. |
| Tensile strength | 35–45 lb/in (M.D. min.) |
| Elongation | 3.0% M.D. min. |
| Elmendorf tear | 229 grams MD min. |
| Adhesion to steel | 30–40 oz/in (at time of manufacture) |
| Color | Tan |
| Size options | 12", 16", 24", 36", 48" widths × 60 yd |
| Shelf life | 1 year from date of manufacture, stored cool/dry out of direct sunlight |
Available Sizes
- 12" (305mm) x 60 yds — P/N MO10V-12
- 16" (406mm) x 60 yds — P/N MO10V-16
- 24" (610mm) x 60 yds — P/N MO10V-24
- 36" (914mm) x 60 yds — P/N MO10V-36
- 48" (1219mm) x 60 yds — P/N MO10V-48
- Color — Tan. Sold by the roll; contact us for case quantities and custom die-cut shapes.
Product Attributes
| Manufacturer | Mask-Off Company, Inc. |
| Manufacturer P/N | PROTEX 10V (MO10V) |
| NSN | 7510-01-121-8267 |
| Country of Origin | United States |
| Color Family | Tan |
| Pack Quantity | 1 Roll or Case |
| Schedule B Code | 4811.59.6000 |
| ECCN | 9A991.d |
Certifications & Approvals
- Boeing — BAC 5034, Type IV, Class 1, Grade A
- NSN — 7510-01-121-8267
- Manufacturer quality — Mask-Off is AS9100C and ISO 9001:2008 certified
Important Notes
- Not intended for fly-away applications
- Test prior to use on copper, brass, or anodized aluminum
- Test prior to outdoor exposure
Technical Data Sheet
Download the Protex 10V Technical Data Sheet (TDS)
Frequently Asked Questions
What is Protex 10V used for?
Protex 10V is a vinyl-coated latex-saturated protective paper used to protect acrylic and polycarbonate windows, canopies, and windshields, bare metal and painted surfaces, leading edges and wing walks, and plexiglass or glass during aircraft paint, fabrication, and assembly operations.
Is Protex 10V the same as elephant skin protective paper?
Protex 10V is a heavy 10 mil latex-saturated paper in the same category commonly nicknamed "elephant skin." Its vinyl coating adds abrasion resistance for demanding aerospace surface protection, and it is qualified to Boeing BAC 5034, Type IV, Class 1, Grade A.
Is Protex 10V silicone-free and safe for aerospace surfaces?
Yes. Protex 10V uses a silicone-free natural latex adhesive to avoid contamination risk on critical aerospace surfaces, and it holds reliably without damaging acrylic, polycarbonate, painted, or bare metal surfaces.
What sizes does Protex 10V come in?
Protex 10V is available in 12", 16", 24", 36", and 48" widths, each on 60-yard rolls, in tan. It can also be die-cut into custom shapes and sizes thanks to its flat release liner.
Is Protex 10V Boeing approved?
Yes. Protex 10V is qualified to Boeing BAC 5034, Type IV, Class 1, Grade A, and carries NSN 7510-01-121-8267. It is manufactured by Mask-Off, an AS9100C and ISO 9001:2008 certified aerospace supplier.
